Wyo VB - Ch. 3 Notes

Objective #1: Use Dim statements to declare variables and understand the physical process of memory (RAM) allocation.

• You should get used to declaring all variables in a program with Dim statements. Such a statement is called a declaration statement. For example,

  Dim sngPrice As Single

  causes 4 bytes of memory (RAM) to be reserved for the value of the variable sngPrice. Furthermore, VB automatically initializes the Single variable to the value 0.0.


• Technically, VB does not require you to declare any variables. However, you should use the

  Option Explicit

  statement at the top of each form to force yourself to declare variables in all programs. It is recommended that you declare all variables though. Other computer programming languages such as C++ require programmers to declare all variables before using them.


• When VB executes a declaration statement, the variable is allocated a certain number of bytes according to the data type specified in the declaration statement. Actually, if a programmer simply uses a declaration statement such as

  Dim sngPrice

  VB will treat the variable as a Variant data type. The common prefixes that most programmers use with variable names have no actual effect on the data type.

Objective #2: Understand each of the basic data types used by Visual Basic.

• You must carefully choose the data type for each variable that you declare in your program.You must use a data type that can store numbers that are in the range of values that you expect the variable to possibly hold during a program's execution. Try not to choose data types that are way too large or you will be guilty of wasting memory space.


• For example, if you needed to store the number of hamburgers sold at a McDonald's restaurant in one day, you should probably use a variable with the Integer data type (to allow for a maximum number of 32,767 hamburgers sold). On the other hand, if you needed to store the number of hamburgers sold on a given day by ALL of the McDonalds restaurants in the U.S., it would probably be necessary to use a variable with the Long data type (to allow for maximum number of 2,147,483, 647 hamburgers).

• You should no longer use the Currency or Variant data types however since the latest version of Visual Basic (version 7) does not support or allow those data types.

• It is dangerous to mix data types in Visual Basic as in the assignment statement,

  sngTotalPrice = intApplesPrice + sngCandyBarPrice

  since an Integer and a Single are being added, there is no guarantee that VB will be able to perform this mixed-mode addition. Realize that you are asking VB to add a 2-byte variable to a 4-byte variable! That is sort of like mixing apples and oranges. Usually, VB will compute a mixed mode expression that involves an Integer variable and a Single variable and round the result. If the expression is being stored to an Integer variable, the result will be rounded! If the expression is being stored to a Single variable the result will have the expected decimal digits. Note that you can't always assume that a programming language allows you to mix data types within expressions. Sometimestruncation will occur causing the decimal portion of a computed number to be lost.

• The reason why an Integer can only store a whole number as high as 32767 is because of the fact that an Integer is 2 bytes in size. Since 2 bytes is equivalent to 16 bits, the largest binary value that can be stored in an Integer is 1111 1111 1111 1111. However, the leading (leftmost) bit (known as the sign bit) is used to keep track of whether the value is positive or negative, so only 15 bits are used to store the variable's actual value. Since 2^15 is 32768, you may think that 32768 should be possible as an Integer value. But since the value 0 must be a possible value, 32767 (which is 2^15 - 1) is the largest value that can be stored in an Integer variable. On the other hand, -32768 is the least (most negative) value that can be stored in an Integer.


• If you try to add one or more to an Integer variable that has the value 32767 an overflow error occurs since the maximum value permitted for an integer is 32767.


Objective #3: Know how to use the InterCap method and the appropriate data type prefixes when naming variables.

• Use sensible and meaningful variable names that make sense. Do not use single letters as variable names like x or y. A program that uses meaningful, descriptive variable names is called self-documenting. This is done so that others (teachers, coworkers, and even yourself) can understand your program easier.


• Variable names along with function and procedure names (we'll study these later) are also considered to be identifiers.


• It is conventional though not required by the VB compiler or interpreter to begin a variable with a prefix that identifies its data type. See the chart above for the standard prefixes. So a good variable name might be intRuns to store the number of runs scored in a baseball game program. However, you may use multiple words to more fully describe the variable's purpose. A better variable name might be intRunsScored. Each word in the variable name (besides the prefix) should be capitalized. This method of capitalizing the words in an identifier is known as the InterCap method of naming variables.


• In most programming languages, including VB, an identifier must begin with a letter and not a digit or a symbol. Thus the variable names 2Many or %More would not be valid. Technically, the variable name int2Many would be valid since an identifier can include digits as long as a letter is the first character. You cannot include a space within an identifier either. Therefore the variable name intRuns Scored would not be valid. To be safe, you should not use more than 31 characters in an identifier either.


• Examples of good variable names:


  • intNumStudents
  • sngSalary
  • sngTotalPrice
  • strFirstName

Objective #4: Use the order of operations to evaluate expressions and to write proper expressions.

• Remember "Please Excuse My Dear Aunt Sally"


• Multiplication & Division are tie, so they must be evaluated from left to right across the expression. That is, it is quite possible to be forced to evaluate a division operation before a multiplication in certain instances.


  • Evaluate the expression, 10 / 5 * 2. Your answer should be 4 and not 1 because the division must be applied before the multiplication.


  • 24 / 8 * 4 = 12 (not 0.75)
  • 20 / 2 * 5 = 50 (not 2)
  • 2 * 2 * 2 / 2 * 2 = 8 (not 2)
  • TRY THIS ONE: 36 / 18 * 2 = ?


• Similarly, addition & subtraction are tie, so they must be evaluated from left to right across the expression as well.
  • 10 - 5 + 5 = 10 (not 0)
  • 100 - 3 + 97 = 194 (not 0)
  • 50 + 60 - 3 + 100 = 207 (not 7)
  • TRY THIS ONE: 100 - 5 + 5 - 5 + 5 = ?


• Expressions are groups of operators and operands that can be evaluated.


  • Examples of expressions:


    • 9 + x - 12
    • (intGame1 + intGame2 + intGame3) / 3


  • Operators
    • unary operators
      • - is the negative sign


    • binary operators
      • + is the addition operator
      • - is the subtraction operator
      • / is the division operator
      • * is the multiplication operator
      • ^ is the exponent operator (e.g. 2 ^ 3 is equal to 8 since 2 to the third power is 8)


  • Operands are the numbers or variables that are bound by the operators.
    • In the expression         x + 3         both x and 3 are operands.

Objective #5: Be able to translate algebraic expressions to Basic.

• Mathematical notation must be written on a single line of code in Basic.
• Insert parentheses where necessary in order to preserve the correct evaluation (that is, you must realize that Basic obeys the order of operations). The rule-of-thumb is to add extra parenthesis when you are in doubt if they are required or not. But note, though, that later in the school year, your teacher may deduct points for unnecessary parentheses in your code.
• Note that Basic computes the two examples below differently behind-the-scenes, even though the final answer may be the same in both cases:


  • sngFahr = 9 * sngCel / 5 + 32
  • sngFahr = 9 / 5 * sngCel + 32

Objective #6: Know how to write assignment statements to evaluate expressions and assign the resulting values to variables and properties.

• Assignment statements evaluate the expression on the right-hand side of the assignment operator (the equals symbol) and assigns the resulting value into the variable on the left-hand side of the assignment operator


• Examples:


  • sngRate = 0.035


  • curInterest = curPrincipal * sngRate * intTime
    (the * refers to multiplication)


  • strMsg = "Enter a Value: "
    (Notice that there is a space after the colon for aesthetic reasons)


  • DO NOT CODE THE FOLLOWING:    x + 8 = y     which is "backwards" as an assignment statement.


• You must be careful distinguish between string data and numeric data (which includes integer, long, single, double, & currency). For example, the string "13" is not equivalent to the value, 13, that may be stored in a variable of the integer datatype. The double quotations are used to show that the string "13" cannot be added, subtracted, etc. from another numeric variable. The quotations acts as delimiters.


  • With the Val command, one could change "13" into 13 as in

    Val("13") = 13.


  • Similarly, one could change the numerical value, 14, into a string with

    Str(14) = "14".

Objective #7: Know how to set break points, examine values of variables and expressions in the Debug window, and single-step through programs.

• Simply highlight the line of code at which you want to set the break point and then click the "Toggle Breakpoint" icon on the toolbar.
• Visual Basic will stop executing the code at that line and allow you to type Print statements into the Debug window. If the Debug window isn't open, select View/Debug Window or click Control-G.
• To single-step through the program once you have stopped its execution at a break point, click the "Step Into" icon on the toolbar. You can continue to check variable values by typing Print statements into the Debug window.

Objective #8: Be familiar with the naming convention used for controls.

•  You must use the InterCap method with the conventional prefixes when naming controls and objects. Always begin a control's name with the correct prefix (3 lowercase letters) that identify the type of control that you are naming.



  Object	Prefix	Example
  Form	frm	frmUserEntry
  Command button	cmd	cmdExit
  Text box	txt	txtDescription
  Label	lbl	lblSum
  Option button	opt	optSingle
  Check box	chk	chkSummary
  Frame	fra	fraChoices
  Horizontal scroll bar	hsb	hsbSpeed
  Vertical scroll bar	vsb	vsbHeight
  Image	img	imgDesign
  Picture box	pic	picFace
  Combo box	cbo	cboList
  List box	lst	lstEntries
  Line	lin	lnHorizon
  Menu	mnu	mnuFile
  Shape	shp	shpRectangle
  Common Dialog	dlg	dlgCommon



• For some labels that you include on a form and occasionally other objects, you may use the default names (e.g. Label1, Label2) that are assigned by Visual Basic. If you do not refer to an object within your code, then you can use its default name.

Objective #10: Be able to change the properties of controls.

• Do not confuse the Text property with the Name property of text boxes. The Text property is what the user can see and possibly modify on the screen. The Name property is what you use as the programmer to organize your program.


• Follow the established naming conventions when you assign your own names to objects such as textboxes, command buttons, and labels. Note that the first three letters of the Name property are all lowercase and identify what type of object the item is. The other word(s) is supplied by the programmer to identify the purpose of the object in the program.


  • Examples: cmdExit, lblClassPeriod, txtLastName
  • You may use some of the names of objects that are assigned by Visual Basic by default. Note that these names do not follow the naming convention explained above. But, if your program (that is, project) includes numerous objects of the same type, it is wise to provide your own, more meaningful, names.


• Some properties only allow True and False values. Experiment with those properties to learn what these settings do. Technically, any nonzero numerical value is equivalent to True and zero is equivalent to False.

Objective #11: Explain how Visual Basic responds to the Click event.

• The Click event adds user interactivity to a program. You must add code to the objects such as command buttons that incorporate this event.

Objective #12: Explain the term event-driven programming.

• Visual Basic makes it easy to create event-driven programs. An event-driven program is one which responds to users' actions such as mouse clicks and mouse movement. Before widespread use of the desktop computer mouse in the late 1980's, it made little sense to create such programs. Nowadays, computer users have more control over the flow of the program and the order of the execution of different tasks. This places new demands on programmers, however. It is important to carefully design a practical and consistent environment when writing VB programs.

• Formerly, programming languages such as older versions of Basic, Pascal, C, FORTRAN, and COBOL were considered to be procedural. The programmer simply wrote lines of code that executed with a sequential flow of control. The compiler or interpreter determined the order of execution of different tasks based on the programmer's original design. Such programs were not as interactive as modern Visual Basic event-driven ones. However, sometimes user interactivity is a hindrance to effective program execution.

Objective #13: Properly design the user interface using objects' TabIndex properties, the SetFocus method, and the focus along with keyboard shortcuts and Clear buttons.

• The TabIndex Property is used to give the user a more user-friendly experience while executing the program. By setting an object's TabIndex Property to 0, a programmer can ensure that the user can immediately enter information into that object (usually a textbox or label). For example, a programmer may want to set the TabIndex Property of a command button to 0 to highlight that button to allow the user to simply press the Enter key to continue with the execution of a program.


• Objects such as command buttons and textboxes have the property called TabIndex. As you create objects and place them on the form, these objects' TabIndex properties are set to the numbers 0, 1, 2, etc. Only one object can have a given a TabIndex property setting of 0, only one object can have a setting of 1, etc. Whichever object has the lowest TabIndex property will first have the focus. By setting a form's objects sequential TabIndex properties (say, from 0 to 7), the programmer can lead the user in a sensible, logical manner during the program execution.


• The focus refers to the object which is selected at any given moment during a program's execution. For example, if the cursor is blinking within a text box, allowing the user to input a number there by typing on the keyboard, that text box is said to have the focus. However, if the user presses the Tab key on the keyboard, then the focus will jump to the object that has the next greatest TabIndex property. Once the user moves the focus to the object with the greatest TabIndex property, pressing the Tab key will cause the focus to return to the original object with the smallest TabIndex property setting (usually 0, not 1).


• You should carefully create objects and place them on a form in the order that you wish the user to be able to access them via the Tab key. In that way, you will not have to manually set the TabIndex properties.


• You should place the ampersand symbol ( & ) before carefully chosen letters within the Captions of command buttons and other objects so that the user can use keyboard shortcuts to activate those objects instead of clicking with the mouse. Some users prefer using the keyboard rather than the mouse. It is the programmer's responsibility to allow for multiple modes of input. Furthermore, you should follow standard Windows conventions when choosing which letter to set as an object's keyboard shortcut. For example, the 'x' in Exit is standard.


• You should place a Clear command button as well as an Exit command buttons when appropriate for a more user-friendly, conventional interface. Within the Clear command button, you usually change the Text properties of text boxes to the null string (aka empty string, ""). Within the Exit button, you should first unload the form with the statement       Unload Me          before typing the statement       End


•   The SetFocus method can be used to purposefully place the focus on a certain object. For example, if you wish the focus to be placed on the Exit button at a particular point in a program's execution so that the user only has to press the Enter key to exit the program, you would use the statement,

  cmdExit.SetFocus


• One command button on a form should have its Default property set to True. This command button will appear shadowed and it's Click event will respond if the user presses the Enter key. You should also set the Cancel property to True for one command button on the form. An obvious candidate for this setting would be a cmdClear or even a cmdExit command button. This command button's Click event will execute if the user presses the Escape (Esc) key in the upper left corner of any keyboard.
